PSU2005 - ACDC Unregulated Power supplies
Product Description: 2000W 230vac to 100Vdc 20Amp
Product Specification
| Part number: | PSU2005 | ||||
| VA: | 2000 | ||||
| Input vac: | 230 | Input current amps: | 8.00 | ||
| Output vac: | 100VDC | Output current amps: | 20.00 | ||
| Case: | P4 Industrial floor/wall mounting case. IP23 | ||||
| Dimensions: | Ht:270 L: 338 W:215 (mm) | Weight: | 16kg | ||
| Surge protection: | SL32 Surge Limitor | ||||
| Type: | Safety Isolating transformer Conforms to EN61558-2-23 CE & RoHS | ||||
| Input Termination: | Screw terminals | ||||
| Primary Protection: | Push to reset circuit breaker SP12 | ||||
| Output Termination: | 2 wayScrew terminal block | ||||
Prices per unit
| 1-4 | 5-24 | 25-49 | 50-99 | 100+ |
| £260.00 | £247.00 | £234.00 | £227.50 | £221.00 |
| Quantity: | ||||
