PS0818 - ACDC Unregulated Power supplies
Product Description: 480VA 230vac to 24Vdc 20Amp
Product Specification
| Part number: | PS0818 | ||||
| VA: | 480 | ||||
| Input vac: | 230 | Input current amps: | 2.00 | ||
| Output vac: | 24VDC | Output current amps: | 20.00 | ||
| Case: | SL300 Powder coated white steel case | ||||
| Dimensions: | Ht:70 W:140 L:230 (mm) | Weight: | 5kg | ||
| Surge protection: | SL15 Surge Limitor | ||||
| Type: | Safety Isolating transformer Conforms to EN61558-2-23 CE & RoHS | ||||
| Input Termination: | Screw terminals | ||||
| Primary Protection: | Glass fuse | ||||
| Output Termination: | Screw terminals | ||||
Prices per unit
| 1-4 | 5-24 | 25-49 | 50-99 | 100+ |
| £130.00 | £123.50 | £117.00 | £113.75 | £110.50 |
| Quantity: | ||||
Part number: PS0818
480VA 230vac to 24Vdc 20Amp
Part number: PS0818
480VA 230vac to 24Vdc 20Amp
